AIR HYDRAULIC RIVETERS, ELECTRIC RIVETERS, CORDLESS RIVETERS, CORDLESS CAULKING GUNS, HAND RIVETERS, RIVETER ADAPTORS AND VARIOUS RIVETS, RIVET NUTS THAT SUITED TO A WIDE RANDGE OF INDUSTRIAL, AUTO REPAIR AND CONSTRUCTION APPLICATIONS.
Specifications :AIR HYDRAULIC RIVETERS, ELECTRIC RIVETERS, CORDLESS RIVETERS, CORDLESS CAULKING GUNS, HAND RIVETERS, RIVETER ADAPTORS AND VARIOUS RIVETS, RIVET NUTS T
Materials :AIR HYDRAULIC RIVETERS, ELECTRIC RIVETERS, CORDLESS RIVETERS, CORDLESS CAULKING GUNS, HAND RIVETERS, RIVETER ADAPTORS AND VARIOUS RIVETS, RIVET NUTS T
Sizes :AIR HYDRAULIC RIVETERS, ELECTRIC RIVETERS, CORDLESS RIVETERS, CORDLESS CAULKING GUNS, HAND RIVETERS, RIVETER ADAPTORS AND VARIOUS RIVETS, RIVET NUTS T
Air riveter, Air hydraulic riveter, Air nut riveter, Air rivet nut tool, riveter adaptor
Specifications :Air riveter, Air hydraulic riveter, Air nut riveter, Air rivet nut tool, riveter adaptor
Materials :Air riveter, Air hydraulic riveter, Air nut riveter, Air rivet nut tool, riveter adaptor
Sizes :Air riveter, Air hydraulic riveter, Air nut riveter, Air rivet nut tool, riveter adaptor
M3-M12 Automatic air hydraulic rivet nut tool
‧Spin-on, Pull-up & Spin-off Action
‧Air pressure: 75-100PSI
‧Speed: 2700RPM
‧Rivet gun traction power: 4565 lbs (2075 kgs)
‧Capacity: M3, M4, M5, M6, M8, M10, M12
‧Work capacity: up to M12 in al. & steel
up to M10 in SS
‧Stroke: 6mm
‧Air Consumption: 1.12 CFM
‧Vibration: 2.5m/S²
‧Weight: 2.38kgs
Specifications :M3-M12 Automatic air hydraulic rivet nut tool
Materials :M3-M12 Automatic air hydraulic rivet nut tool
Sizes :M3-M12 Automatic air hydraulic rivet nut tool
3/16” Air hydraulic riveter kit
1.AHR-101 Air riveter x 1 2.Rivets 3/16" x 10
3.Rivets 5/32" x 10 4.Rivets 1/8" x 10
5.Rivets 3/32" x 10 6.Oiler x 1 7.Joint nut x 1
8.Swivel joint x 1 9.Nosepiece, 3/16" x 1
10. Nosepiece, 5/32" x 1 11.Nosepiece, 1/8" x 1
12.Nosepiece, 3/32" x 1 13.Jaw Case, Front x 1
14. Jaw x 2 15.Jaw Pusher x 1 16. Jaw Case, Rear x 1
17. Spring, Jaw Pusher x 1 18.O Ring x 10
19.Backup Ring x 3 20. Spanner x 1 21.Spring x 1 22.Safety Cap x 1 23. Nut, Frame Cap x 1
24.Spring, Valve x 1 25.Collar, Valve x 1
26.Piston Ring x 1 27.Spring, Valve x 1
28.Spanner Gauge x 1
Specifications :3/16” Air hydraulic riveter kit
Materials :3/16” Air hydraulic riveter kit
Sizes :3/16” Air hydraulic riveter kit
‧Voltage: 7.2V (Li-ion battery)
‧Max thrust: 450Kgf ± 45
‧No load speed: 5.5mm/sec
‧Overall length: 380mm
‧Carriage: 9"(Cartridge 310ml, Sausage 400ml)
‧Dripless
‧Net Weight: 1.3kgs
‧Size: 380mm(L)*225mm(H)*70mm(W)
Specifications :7.2V Li-ion Cordless caulking gun
Materials :7.2V Li-ion Cordless caulking gun
Sizes :7.2V Li-ion Cordless caulking gun
‧Voltage: 7.2V Li-ion battery
‧Rivet capacity: up to 3/16" (4.8mm)
‧Max traction power: 800 kgf (1760 lbs)
‧Stroke: 18mm
‧Work capacity: up to 4.8 in Al. & steel, up to 4mm in SS
‧Net weight: 1.05 kgs (2.31 lb)
Specifications :3/16” Cordless riveter
Materials :3/16” Cordless riveter
Sizes :3/16” Cordless riveter
M4-M10 Semi-automatic air hydraulic rivet nut tool
‧Traction power: 2680 lbs (1219kgs)
‧Tool stroke: 6.5mm
‧Air consumption: 3CFM
‧Mandrels size: M4-M5-M6-M8-M10
‧Work capacity: up to M10 in al. & steel nuts
up to M6 in stainless nuts
‧Weight: 1.63kgs
Specifications :M4-M10 Semi-automatic air hydraulic rivet nut tool
Materials :M4-M10 Semi-automatic air hydraulic rivet nut tool
Sizes :M4-M10 Semi-automatic air hydraulic rivet nut tool
‧Rivet Capacity: For setting blind rivets up to 4.8mm
‧Nosepieces: 3.2mm, 4.0mm, 4.8mm
‧Work capacity: up to 4.8mm in al. & steel; up to 4mm in stainless
‧Traction Power: 1960 lbs (890 kgs)
‧Tool Stroke: 15.5mm
‧Working Pressure: 71~85PSI
‧Air inlet: 1/4” PT
‧Weight: 3.3lbs (1.5kgs)
Specifications :3/16” Air hydraulic riveter
Materials :3/16” Air hydraulic riveter
Sizes :3/16” Air hydraulic riveter
‧Min. torque strength: 8 ft/lbs (11 Nm)
‧Max. rpm: 1000 rpm
‧Nosepiece: 2.4mm-3.2mm.4.0mm-4.8mm
‧Work capacity: up to 4.8mm in SS
‧Hex shank: 1/4"(6.35mm)
‧Dimension: 59mm x 158mm
‧Suit for 12V-14.4V-18V cordless drill/drive; reversible electric drill/drive; reversible air drill/drive
Specifications :3/16 Riveter adaptor
Materials :3/16 Riveter adaptor
Sizes :3/16 Riveter adaptor
‧Min. torque strength: 8 ft/lbs (11 Nm)
‧Max. rpm: 1000 rpm
‧Nosepiece: 2.4mm-3.2mm.4.0mm-4.8mm
‧Work capacity: up to 4.8mm in SS
‧Hex shank: 1/4"(6.35mm)
‧Dimension: 59mm x 158mm
‧Suit for 12V-14.4V-18V cordless drill/drive; reversible electric drill/drive; reversible air drill/drive
Specifications :3/16 Riveter adaptor
Materials :3/16 Riveter adaptor
Sizes :3/16 Riveter adaptor
‧Min. torque strength: 73.7 ft/lbs (100 Nm)
‧Max. rpm: 800 RPM
‧Nut Nosepiece: M6-M8-M10
‧Hex shank: 1/4"(6.35mm)
‧Dimension: 59mm x 180mm
‧Suit for 14.4V-18V cordless drill/drive; reversible electric drill (advice 500W); reversible air drill (advice 1/2”)
Specifications :M6-M10 Nut Riveter Adaptor
Materials :M6-M10 Nut Riveter Adaptor
Sizes :M6-M10 Nut Riveter Adaptor
‧Min. torque strength: 73.7 ft/lbs (100 Nm)
‧Max. rpm: 800 rpm
‧Nut Nosepiece: M4-M5-M6-M8-M10
‧Hex shank: 6.35mm
‧Dimension: 36mm x 127mm
‧Suit for 14.4V-18V cordless drill/drive; reversible electric drill (advice 500W); reversible air drill (advice 1/2”)
Specifications :M4-M10 Nut riveter adaptor-alu. housing
Materials :M4-M10 Nut riveter adaptor-alu. housing
Sizes :M4-M10 Nut riveter adaptor-alu. housing
7.2V Li-ion cordless caulking gun
Specifications :7.2V Li-ion cordless caulking gun
Materials :7.2V Li-ion cordless caulking gun
Sizes :7.2V Li-ion cordless caulking gun
‧Voltage: 7.2V (Li-ion battery)
‧Max thrust: 600kgf ± 60
‧No load speed: 4.0mm/sec
‧Capacity: 380ml (10:1) coaxial cartridge
‧Net Weight: 1.55kgs
‧Size: 356mm(L)*224mm(H)*70mm(W)
Specifications :7.2V Li-ion cordless epoxy gun
Materials :7.2V Li-ion cordless epoxy gun
Sizes :7.2V Li-ion cordless epoxy gun
‧Voltage: 7.2V (Li-ion battery)
‧Max thrust: 600kgf ± 60
‧No load speed: 4.0mm/sec
‧Capacity: 345ml (10:1)& 400ml (3:1) cartridge
‧Net Weight: 1.57kgs
‧Size: 387mm(L)*224mm(H)*82mm(W)
Specifications :7.2V Li-ion cordless epoxy gun
Materials :7.2V Li-ion cordless epoxy gun
Sizes :7.2V Li-ion cordless epoxy gun
‧Voltage: 7.2V (Li-ion battery)
‧Max thrust: 600kgf ± 60
‧No load speed: 4.0mm/sec
‧Capacity: 400ml (1:1)cartridge
‧Net Weight: 1.72kgs
‧Size: 387mm(L)*224mm(H)*101mm(W)
Specifications :7.2V Li-ion cordless epoxy gun
Materials :7.2V Li-ion cordless epoxy gun
Sizes :7.2V Li-ion cordless epoxy gun
‧Voltage: 7.2V (Li-ion battery)
‧Max thrust: 600kgf ± 60
‧No load speed: 4.0mm/sec
‧Capacity: 385ml (2:1)& 585ml (2:1) cartridge
‧Net Weight: 1.71kgs
‧Size: 414mm(L)*223mm(H)*97mm(W)
Specifications :7.2V Li-ion cordless epoxy gun
Materials :7.2V Li-ion cordless epoxy gun
Sizes :7.2V Li-ion cordless epoxy gun
‧Rivet capacity: up to 3/16"
‧Traction power: 2680lbs (1219kgs)
‧Stroke length: 14mm
‧Nosepieces: 2.4mm, 3.2mm, 4.0mm, 4.8mm
‧Acceptable rivet material: aluminum/steel/stainless
‧Working pressure: 60~100PSI
‧Weight: 3.3lbs (1.5kgs)
Specifications :3/16” Air hydraulic riveter
Materials :3/16” Air hydraulic riveter
Sizes :3/16” Air hydraulic riveter
‧Rivet capacity: for setting blind rivets up to 3/16” (4.8mm)
‧Nosepieces: 2.4mm, 3.2mm, 4.0mm, 4.8mm
‧Max Capacity: up to 4.8mm in al. & steel
up to 4mm in SS
‧Traction power: 2680lbs (1219kgs)
‧Tool stroke: 14mm
‧Working pressure: 60~100PSI (depend on rivet material)
‧Air inlet: 1/4”
‧Weight: 3.5lbs (1.6kgs)
Specifications :3/16” Air hydraulic riveter- quick repair type
Materials :3/16” Air hydraulic riveter- quick repair type
Sizes :3/16” Air hydraulic riveter- quick repair type
‧Rivet Capacity: for setting blind rivets up to 3/16” (4.8mm)
‧Nosepieces: 2.4mm, 3.2mm, 4.0mm, 4.8mm
‧Max Capacity: up to 4.8mm in al. & steel; up to 4mm in stainless
‧Traction Power: 2508lbs (1140kgs)
‧Tool Stroke: 16mm
‧Working pressure: 60~100PSI (depend on rivet material)
‧Air inlet: 1/4”PT
‧Weight: 3.2lbs (1.45kgs)
Specifications :3/16” Air hydraulic riveter
Materials :3/16” Air hydraulic riveter
Sizes :3/16” Air hydraulic riveter
‧Rivet capacity: up to 3/16"
‧Traction power: 2680lbs (1219kgs)
‧Stroke length: 14mm
‧Nosepieces: 2.4mm, 3.2mm, 4.0mm, 4.8mm
‧Acceptable rivet material: aluminum/steel/stainless
‧Working pressure: 60~100PSI
‧Weight: 3.3lbs (1.5kgs)
Specifications :3/16” Air hydraulic riveter W/ vacuum
Materials :3/16” Air hydraulic riveter W/ vacuum
Sizes :3/16” Air hydraulic riveter W/ vacuum
Power source: AC230V
Power consumption: 230V, 50Hz, 25W
Heating time: only 10 seconds
Three temperature choices
Stainless heating pin, avoids deformation
Specifications :Hot stapler
Materials :Hot stapler
Sizes :Hot stapler
