Cordless Riveter, Industrial-grade Pneumatic Hydraulic Riveting Tools, Industrial-grade Pneumatic Hydraulic Rivet Nut Tools, Air Engraving Pen, Air Nibbler Tool, Air Hydraulic Spin Pull Tool , Air Riveting Lock Bolt Gun for Huck, Lndustrial Grade Electric Riveting Tools, Battery Blind Rivet Gun , Cordless Lockbolt Tool.
Specifications :CCP-ER-1, CCP-ER-2
Air Hydraulic Riveters, Air Spin-Pull Rivet Nut Tool, Air Riveting Tool, Lock Bolt Installation Tool, Air Hydraulic Rivnut
http://www.ccptool.com
Specifications :Air Hydraulic Riveters, Air Spin-Pull Rivet Nut Tool
Hydraulic Riveters,Rivnut Tools,Nibbler,Engraving Pen
Specifications :Hydraulic Riveters,Rivnut Tools,Nibbler,Engraving Pen
Materials :Hydraulic Riveters,Rivnut Tools,Nibbler,Engraving Pen
Sizes :Hydraulic Riveters,Rivnut Tools,Nibbler,Engraving Pen
Air Spin-Pull Rivet Nut TOOL,Air Riveter,Lock Bolt Installation Tool
Specifications :Air Spin-Pull Rivet Nut TOOL,Air Riveter,Lock Bolt Installation Tool
. Work Capacity: up to 3/16 inch in all materials
. Stroke: 16 mm (0.63 inch)
. Working Air Pressure: 85 ~ 100PSI (6 ~ 7 kg/cm2)
. Traction Power: 1983lbs (8820n)
. Nosepieces: 1/8, 5/32, 3/16 inch
(3.2, 4.0, 4.8 mm)
. Tool Weight: 1.46 kg
. Height: 298 mm
. Length of Placing Head: 225 mm
. Base Diameter: 74 mm
https://www.ccptool.com
Specifications :CCP-700A, Air Hydraulic Riveter-3/16 Inch
. Industry type
. Cutting Capacity: 18 gauge (1.2 m/m)
. Stroke per Minute: 210
. Cutting Speed: 5.2 FRM
. Net Weight: 3 lbs
. Speed: 2600 SPM
. Overall Length: 8 inches
. Air Consumption: 4 CFM
. Air Inlet: 1/4 inch
. Minimum Hose Size: 3/8 inch
https://www.ccptool.com
Specifications :CCP-600 ,Air Nibbler
.Work Capacity: for setting standard rivets 2.4 ~ 4.8 mm (3/32 ~ 3/16 inch) in all materials
.Stroke: 23.5 mm (0.925 inch)
.Working Air Pressure: 85 ~ 95 PSI (6 ~ 6.7 kg/cm2)
.Traction Power: 2100 lbs (953.4kg)
.Nosepieces: 3/16, 5/32, 1/8, 3/32 inch (4.8, 4.0, 3.2, 2.4 mm)
.Vacuum: Yes
https://www.ccptool.com
Specifications :CCP-270, Air Hydraulic Blind Riveter 3/16 Inch
. Stroke: 22.5 mm (0.88 inch)
. Working Air Pressure: 85 ~ 95 PSI (6 ~ 6.7 kg/cm2)
. Traction Power: 3800 lbs (1723kg)
. Nosepieces: 3/16, 7/32, 1/4, 5/16 inch
(4.8, 5.6, 6.4, 7.8 mm)
. Vacuum: yes
http://www.ccptool.com
Specifications :CCP-380, Air Hydraulic Blind Riveter 5/16 Inch
.This Huckbolt riveting tool is ideal for many truck and trailer repair applications. It is also designed to install the C98LT stainless steel polished Huck bolts used on the Peterbilt Truck Cab grills. These tools are often referred to as Huck tools. Also included are wrenches for service and oil applicator.
A structural, two-piece fastener, which consists of a pin (C6L lockbolt) and a collar (C6L collar).
During installation, the collar is swaged on to the bolt, resulting in a permanent, high strength, vibration resistant installation.
Installs with consistency and provides a high uniform clamp force
. Heavy-duty design and long service life, high quality parts special treatment
。Low pressure can be action
. Stroke: 24 mm (0.94 inch)
. Working Air Pressure: 70 ~ 95 PSI (4.9 ~ 6.7 kg/cm2)
. Ave. Air Consumption: 4 CFM
. Traction Power: 4480 lbs (2033kg)
. Nosepieces: MAGNA-LOK 4.8mm(3/16”)~6.4mm(1/4”) MAGNA-BULB 4.8mm(3/16”)~6.4mm(1/4”) C6L 4.8mm(3/16”)~6.4mm(1/4”) MAGNA-GRIP 4.8mm(3/16”)~6.4mm(1/4”) BOM4.8mm(3/16”)
. Tool Weight: 1.74 kg
https://www.ccptool.com
Specifications :CCP-380HK, Huck Pneumatic Tools Air Hydraulic Riveter
. Work Capacity: for setting standard blind rivets
2.4 ~ 4.8 mm (3/32 ~ 3/16 inch) in all
materials
. Stroke: 15 mm (0.59 inch)
. Working Air Pressure: 85 ~ 95 PSI (6 ~ 6.7 kg/cm2)
. Traction Power: 2000 lbs (908kg)
. Nosepieces: 3/16, 5/32, 1/8, 3/32 inch
(4.8, 4.0, 3.2, 2.4 mm)
. Vacuum: yes
https://www.ccptool.com
Specifications :CCP-190 , Air Hydraulic Blind Riveter 3/16 Inch
.Can use the standard (M3 ~ M8)&(6-32 ~ 5/16-18UNC) rivet nut all materials.
.tie-rod sizes:(M3,M4,M5,M6,M8)&(#6, #8, #10, 1/4, 5/16 inch)
Stroke: 7 mm (0.276 inch)
Working Air Pressure: 85 ~ 95 psi (5.9 ~ 6.68 kg/cm2)
Pull Force (85 psi): 1452 kg (3200 lbs)
https://www.ccptool.com
Specifications :CCP-20 , Air Hydraulic Spin-pull Rivet Nut Tools
. for setting standard spin pull tool
(6-32 ~ 1/2-13UNC);(M3 ~ M12 ) in all materials
. Rivet Nut Sizes: (#6, #8, #10, 1/4, 5/16, 3/8, 1/2 inch ); (M3, M4, M5, M6, M8, M10, M12 )
. Stroke: 7 mm (0.276 inch)
. Working Air Pressure: 85 ~ 95 psi (5.9 ~ 6.7 kg/cm2)
. Pull Force (85 psi): 2176 kg (4800 lbs)
https://www.ccptool.com
Specifications :CCP-25 / Air Hydraulic Rivnut Tools
. Stroke: 15 mm (0.59 inch)
. Working Air Pressure: 85 ~ 95 PSI (6 ~ 6.7 kg/cm2)
. Traction Power: 3700 lbs (16458 n)
. Nosepieces: 3/16, 7/32, 1/4 inch
(4.8, 5.6, 6.4 mm)
. Vacuum: yes
https://www.ccptool.com
Specifications :CCP-350, Air Hydraulic Blind Riveter 1/4 Inch
. Stroke: 19.5 mm (0.768 inch)
. Working Air Pressure: 85 ~ 90PSI (6 ~ 6.3 kg/cm2)
. Traction Power: 2400 lbs (10675 n)
. Nosepieces: 3/32, 1/8, 5/32, 3/16 inch
(2.4, 3.2, 4.0, 4.8 mm)
.Auto Vacuum Mandrel Collection System: Yes
https://www.ccptool.com
Specifications :CCP-240, Air Hydraulic Blind Riveter 3/16 Inch
. Work Capacity: Up to 1/4 inch in all materials
. Stroke: 19 mm (0.748 inch)
. Working Air Pressure: 85 ~ 100 PSI (6 ~ 7 kg/cm2)
. Traction Power: 3099lbs (13784n)
. Nosepieces:
3/32, 1/8, 5/32, 3/16, 7/32, 1/4 inch
(2.4, 3.2, 4.0, 4.8, 5.6, 6.4 mm)
. Tool Weight: 2.07 kg
. Height: 324 mm
. Length of Placing Head: 260 mm
. Base Diameter: 94 mm
http://www.ccptool.com
Specifications :CCP-500 , Air Hydraulic Rivet Tool 1/4 Inch
. Weight: 0.19 kg (0.42 lbs)
. Length: 170 mm (6.7 inches)
. Air Inlet: 1/4 inch
. Working Pressure: 60 ~ 90 PSI
https://www.ccptool.com
. Ave. Air Consumption: 2 CFM
. BPM: 3500 ~ 3800
. Tool Weight: 0.19 kg
. Height: 1690 mm
. Base Diameter: 16 mm
Specifications :CCP-909, Air Engraving Pen
Weight: 0.18 kg (0.4 lbs)
. Lengh: 140 mm (5.52")
. Air Inlet: 1/4"
. Working Pressure: 60 ~ 90 PSI
. Ave. Air Consumption: 2 CFM
. BPM: 3300 ~ 3400
. Tool Weight: 0.18 kg
. Length of Placing Head: 1650 mm
. Base Diameter: 24 mm
https://www.ccptool.com
Specifications :CCP-908, Air Engraving Pen
Work Capacity: up to 1/4 inch in all materials
Traction Power: 3500lbs (1589kg )
Stroke: 14 mm (0.551 inch)
Working Air Pressure: 85 ~ 100PSI (6 ~ 7 kg/cm2)
Nosepieces: 3/32, 1/8, 5/32, 3/16, 7/32, 1/4 inch (2.4, 3.2, 4.0, 4.8, 5.6, 6.4 mm)
Vacuum: No
https://www.ccptool.com
Specifications :CCP-500M / Air Rivet Tools1/4 Inch
.Can use the standard (M4 ~M12)& (8-32 ~ 1/2-13UNC) rivet nut all materials.
.tie-rod sizes:(M4,M5,M6,M8,M10,M12)&(#8,#10,1/4,5/16,3/8,1/2 inch)
.Stroke: 7 mm (0.276 inch)
.Working Air Pressure: 85 ~ 95 psi (5.9 ~ 6.68 kg/cm2)
.Pull Force (85 psi): 2724 kg (6000 lbs)
https://www.ccptool.com
Specifications :CCP-30M, Air Hydraulic Spin-pull Rivet Nut Tools
